ACCENTO DYNAMICA
9
SERIES MODELS
5¼”
ADS525FT6
Code
ADS525FT6
Size
5¼”
Input
8Ω / 100V Taps 6W / 3W / 1.5W
Freq.
186HZ-20KHZ
Pmax
12W
Prms
6W
Sens.
87dB
Packaging
Single
METAL FRAME
Compact general purpose PA speaker.
Paper pulp cone wide range with whizzer cone
for high end sound. Reliable metal construction
Finger spring mount system. Built-in line
transformer with 6W-3W-1.5W (8 Ohm) Taps.
82mm
89mm
Outside
Diameter
Ø 181mm
Mounting
Cut out
Hole Dia.
Ø 150mm
6½”
ADS65FT10
Code
ADS65FT10
Size
6½”
Input
8Ω / 100V Taps 10W / 5W / 2.5W
Freq.
178HZ-20KHZ
Pmax
20W
Prms
10W
Sens.
87dB
Packaging
Single
METAL FRAME
Compact general purpose PA speaker.
Paper pulp cone wide range with whizzer cone for
high end sound. Reliable metal construction
Finger spring mount system. Built-in line
transformer with 10W-5W-2.5W (8 Ohm) Taps.
8”
ADS8FT10
Code
ADS8FT10
Size
8”
Input
8Ω / 100V Taps 10W / 5W / 2.5W
Freq.
90HZ-20KHZ
Pmax
20W
Prms
10W
Sens.
87dB
Packaging
Single
METAL FRAME
Compact general purpose PA speaker.
Paper pulp cone wide range with whizzer cone
for high end sound. Reliable metal construction
Finger spring mount system. Built-in line
transformer with 10W-5W-2.5W (8 Ohm) Taps.
85mm
92mm
Outside
Diameter
Ø 199mm
Mounting
Cut out
Hole Dia.
Ø 165mm
103mm
110mm
Outside
Diameter
Ø 245mm
Mounting
Cut out
Hole Dia.
Ø 214mm
METAL FRAME
Excellent cost effective solution.
Single piece stamped metal frame
with a metal grille front fascia.
DUAL-CONE SYSTEM
Paper pulp full range speaker
cone. Whizzer cone for high
end response.
APPLICATION
Suitable for most PA type
applications, these drivers include
a 100V Line transformer with
voltage taps via bare wires for
in-line type connection enabling
multiple speaker setups. For
8 Ohm input, the transformer
should be disconnected and
the 8 Ohm input wired to the
speaker directly.
100V PA CEILING SPEAKER DUAL-CONE
METAL HOUSING
