ACCENTO DYNAMICA
5
SERIES MODELS
100V-LINE CEILING & WALL MOUNT SPEAKERS
5¼”
ADS1550
Code
ADS1550
Size
5¼”
Input
8Ω / 100V Taps 6W / 3W / 1.5W
Pmax
100W
Prms
50W
Freq.
70Hz-20Khz
Sens.
88dB
Packaging
Single
KEVLAR & TITANIUM
High performance Audiophile grade.
2-Way coaxial with PTC Overdrive
protected titanium coated tweeter.
5¼” Kevlar Mid-Woofer. High Power,
Long life and Hi-Fidelity. Input Options:
8 Ohm & 100V 6W / 3W / 1.5W Taps.
Ø175mm
114.5
127
23
Ø213mm
Ø175mm
Mounting
Hole
6½”
ADS1660
KEVLAR & TITANIUM
High Performance. PTC Protected
titanium tweeter with adjustable
tilt. Kevlar 6½” Woofer Aluminium
voice coil. High Power, Long life and
Hi-Fidelity. Input Options: 8 Ohm &
100V 30W / 15W / 7.5W Taps.
Ø203mm
139
155
23
Ø239mm
Ø203mm
Mounting
Hole
8”
ADS1880
Code
ADS1880
Size
8”
Input
8Ω / 100V Taps
50W / 25W / 12.5W
Pmax
160W
Prms
80W
Freq.
50HZ-20KHZ
Sens.
90dB
Packaging
Single
POLYPROPYLENE
High Performance. PTC Protected
titanium tweeter with adjustable tilt.
Kevlar 8” Woofer with aluminium
voice coil. High Power, Long life and
Hi-Fidelity. Input Options: 8 Ohm &
100V 50W / 25W / 12.5W Taps.
Ø245mm
175
190
23
Ø280mm
Ø245mm
Mounting
Hole
Code
ADS1660
Size
6½”
Input
8Ω / 100V Taps 30W / 15W / 7.5W
Pmax
120W
Prms
60W
Freq.
66Hz-20Khz
Sens.
88dB
Packaging
Single
8”
LOW PROFILE
ADS1850
KEVLAR & TITANIUM
Suitable Small Ceiling cavity. 2-Way
coaxial with Titanium Tweeter &
Polypropylene 8” woofer for superior
bass. Aluminium voice coil. High Power,
Long life and Hi-Fidelity. Input Options:
8 Ohm & 100V 30W / 15W / 7.5W Taps.
Ø245mm
99
114
23
Ø280mm
Ø245mm
Mounting
Hole
Code
ADS1850
Size
8”
Input
8Ω / 100V Taps 30W / 15W / 7.5W
Pmax
100W
Prms
50W
Freq.
45HZ-20KHZ
Sens.
88dB
Packaging
Single
ENCLOSED CABINET / SEISMIC CABLE
Sealed cabinet design protects speaker back, no dirt, no dust and
no vermin. Gives better bass and reduce cavity vibration with
Attachment point for seismic cable (safety cable).
SAFETY PLASTIC
Constructed from Fire retardant plastics to UL-8540T.
TILT COAXIAL TWEETER
High quality Titanium tweeter for beautiful
sound and high end response. Tweeter can
be tilted to give directionality to sound and
an attenuator switch for softening presence
and flawless sound.
HI-END WOOFER CONSTRUCTION
Cone construction is made from woven
Kevlar material designed for premium
sound quality audio & warm bass.
Mounted in an anodized metal basket
with butyl rubber surround for long
exertion high SPL efficiency, low
resonance and long life durability.
CROSS-OVER NETWORK
Engineered using high quality components
designed to perfectly match the tweeter and
woofer for exceptional sound reproduction.
