ACCENTO DYNAMICA
3
SERIES MODELS
FAST INSTALL
Rapid Push-Release mounting system. 25mm
Silk dome tweeter with tilt adjust with high range
attenuator switch 12dB/Octave electronic crossover.
Yellow woven Kevlar mid-woofer 6½”. Long-life Butyl
Rubber roll surround. Aluminium high temp’ voice
coil. Anodised steel frame back grille.
HiFi HIGH PERFORMANCE CEILING MOUNT
FAST INSTALLATION
6½”
ADS65F40
Code
ADS65F40
Size
6½”
Freq.
55HZ-20KHZ
Input
8Ω
Pmax
80W
Prms
40W
Sens.
87dB
Packaging
Pair
Outside
Diameter
Ø 237mm
Mounting
Cut out
Hole Dia.
Ø 213mm
IN+
IN-
Ø 213mm
85mm
75mm
8”
ADS8F80
Code
ADS8F80
Size
8”
Freq.
53HZ-20KHZ
Input
8Ω
Pmax
160W
Prms
80W
Sens.
90dB
Packaging
Pair
FAST INSTALL
Rapid Push-Release mounting system. 25mm
Silk dome tweeter with tilt adjust with high range
attenuator switch 12dB/Octave electronic crossover.
Yellow woven Kevlar mid-woofer 8”. Long-life Butyl
Rubber roll surround. Aluminium high temp’ voice
coil. Anodised steel frame back grille.
Outside
Diameter
Ø 275mm
Mounting
Cut out
Hole Dia.
Ø 245mm
Ø 245mm
108mm
92mm
IN-
IN+
6½”
ADS365F40
Code
ADS365F40
Size
6½”
Freq.
55HZ-20KHZ
Input
8Ω
Pmax
80W
Prms
40W
Sens.
87dB
Packaging
Pair
FAST INSTALL
Rapid Push-Release mounting system.
Independent 25mm Silk dome tweeter with tilt
adjust with high range attenuator switch 12dB/
Octave electronic crossover. Yellow woven Kevlar
mid-woofer 8”. Long-life Butyl Rubber roll surround.
Aluminium high temp’ voice coil. Anodised steel
frame back grille.
286mm
310mm
79.3mm
72.3mm
196mm
172mm
+NI
-NI
w+w-
RAPID INSTALLATION SYSTEM !
Unique Push-To-Release spring loaded auto mounting clamps. Spiral fastener auto-fits ceiling
depth 10-25mm. Use the ¼” Allen Key (Included) for easy half-turn release of the clamp to
remove the speaker. Time saving, simple, reliable and no-fuss mounting process.
MICRO-FLANGE
Modern low profile flange design that’s unobtrusive and slim line that
will suit traditional and modern decor’s seamlessly.
TILT COAXIAL TWEETER
High quality 1” Silk dome ferro fluid cooled
neodymium magnet tweeter for beautiful sound
high end response. Tweeter can be tilted to give
directionality to sound and an attenuator switch
for softening presence and flawless sound.
HI-END WOOFER CONSTRUCTION
Cone construction is made from woven
Kevlar material designed for premium
sound quality audio & warm bass.
Mounted in an anodized metal basket
with butyl rubber surround for long
exertion high SPL efficiency, low
resonance and long life durability.
CROSS-OVER NETWORK
Engineered using high quality components
designed to perfectly match the tweeter and
woofer for exceptional sound reproduction.
12dB/Octave with adjustable 0dB / 3dB / 6dB
Tweeter level adjustment.
RAPID INSTALL SYSTEM
8 SECOND INSTALLATION.
SEE PAGE 8 FOR DETAILS
