ACCENTO DYNAMICA
SERIES MODELS
8
100V PA CEILING SPEAKER RAPID INSTALL
6½”
ADS65FT15
Code
ADS65FT15
Size
6½”
Input
8Ω / 100V Taps 15W / 10W / 6W / 3W / 1.5W
Freq.
80HZ-20KHZ
Pmax
30W
Prms
15W
Sens.
87dB
Packaging
Single
FAST INSTALL
Rapid Push-Release mounting system Quick &
easy Install in seconds ! 25mm Aluminium High
Temp voice coil Paper pulp HiFi mid-woofer
speaker. Durable doped cloth roll surround
Centre pole mounted coaxial tweeter 13mm
dynamic PEI tweeter.
8”
ADS8FT15
Code
ADS8FT15
Size
8”
Input
8Ω / 100V Taps 15W / 10W / 6W / 3W / 1.5W
Freq.
62HZ-20KHZ
Pmax
30W
Prms
15W
Sens.
87dB
Packaging
Single
FAST INSTALL
Rapid Push-Release mounting system Quick &
easy Install in seconds ! 25mm Aluminium High
Temp voice coil Paper pulp HiFi mid-woofer
speaker. Durable doped cloth roll surround
centre. Pole mounted coaxial tweeter 13mm PEI
dynamic tweeter.
138mm
Ø245mm
Outside
Diameter
Ø 275mm
Mounting
Cut out
Hole Dia.
Ø 245mm
154mm
Ø
213mm
75mm
72mm
Outside
Diameter
Ø 237mm
Mounting
Cut out
Hole Dia.
Ø 213mm
Insert Speaker into Installation Location
1
Use the thin side of the L shaped wrench to
install the speaker. Simple push to release
mounting tabs! Tabs will automaticaly release
mount speaker to the ceiling.
ReleasedTabs
Lock Speaker
into Ceiling
Required ceiling thickness
must be between 10mm ~ 25mm
2
RAPID INSTALLATION SYSTEM !
Unique Push-To-Release spring loaded auto
mounting clamps. Spiral fastener auto-fits
ceiling depth 10-25mm. Use the ¼” Allen
Key (Included) for easy half-turn release
of the clamp to remove the speaker.
Time saving, simple, reliable and no-fuss
mounting process.
2-WAY COAXIAL SYSTEM
High quality 13mm PEI dynamic tweeter
for enhanced high frequency response.
APPLICATION
Suitable for most PA type
applications, these drivers include
a 100V Line transformer with
voltage taps via bare wires for
in-line type connection enabling
multiple speaker setups. For
8 Ohm input, the transformer
should be disconnected and
the 8 Ohm input wired to the
speaker directly
.
RAPID INSTALL
8 SECOND INSTALLATION
