Accento Dynamica 2013 Sound Solutions Catalogue - page 2

ACCENTO DYNAMICA
SERIES MODELS
2
MICRO-FLANGED STYLE.
35mm aluminium voice coil. Black fibre-glass cone
Inverted dust cap. Butyl rubber surround Anodized
metal basket. 25mm Silk dome tweeter with Ferro
fluid cooled Neodymium magnet. 8Ω Input, 12dB/
Octave cross-over. Push Terminals. High Sensitivity
90dB/1W. Easy Swivel clamp mounting.
6½”
ADS65M50
Code
ADS65M50
Size
6½”
Freq.
61HZ-20KHZ
Input
Pmax
100W
Prms
50W
Sens.
89dB
Packaging
Pair
MICRO-FLANGED STYLE.
25mm aluminium voice coil. Black fibre-glass cone
Inverted dust cap. Butyl rubber surround Anodized
metal basket. 25mm Silk dome tweeter with Ferro
fluid cooled Neodymium magnet. 8Ω Input, 12dB/
Octave cross-over. Push Terminals. High Sensitivity
90dB/1W. Easy Swivel clamp mounting.
Outside
Diameter
Ø 226mm
Mounting
Cut out
Hole Dia.
Ø 202mm
WF+OUTTW+
-6dB -3dB0dBS
P35-M6RSST-1B
IN-
IN+
Ø 202mm
103mm
95.5mm
8”
ADS8M80
Code
ADS8M80
Size
8”
Freq.
40HZ-20KHZ
Input
Pmax
160W
Prms
80W
Sens.
90dB
Packaging
Pair
Outside
Diameter
Ø 270mm
Mounting
Cut out
Hole Dia.
Ø 244mm
Ø 244mm
118mm
111mm
MICRO-FLANGE
Modern low profile flange design that’s unobtrusive
and slim line that will suit traditional and modern
decor’s seamlessly.
SUSPENDED TWEETER SYSTEM
High quality 1” Silk dome ferro fluid cooled
neodymium magnet tweeter for beautiful sound
high end response, mounted independently
and suspended from the woofer to ensure the
tweeter and woofer work in perfect harmony.
HI-END WOOFER CONSTRUCTION
Cone construction is made from black
woven fibre-glass material designed
and constructed to be light but rigid for
excellently controlled tight bass with live
natural sound. Mounted in an anodized
metal basket with butyl rubber surround
for long exertion high SPL efficiency, low
resonance and long life durability.
CROSS-OVER NETWORK
Engineered using high quality components
designed to perfectly match the tweeter
and woofer for exceptional sound
reproduction. 12dB/Octave with adjustable
0dB / 3dB / 6dB Tweeter level adjustment.
HiFi PREMIUM PERFORMANCE CEILING MOUNT
SUSPENDED TWEETER SYSTEM
BE HEARD
SEND YOUR message
LOUD & CLEAR
